300-700mA 15W LED Driver （CC）
MIW-15

Super compact design for built-in use

Universal AC input (100-277V AC)

Analogue flicker-free

Configurable constant current output via dip-switch

Primary and secondary sides come with leads

Protections: opencircuit, shortcircuit, overload, overtemperature

Seal with glue, the operating temperature up to 60℃

Differential mode 2kV and common mode 4kV surge immunity

SELV equivalent

EOFi=0.95

Suitable for protection class I & II luminaires
