200-350mA 15W TRIAC Dimming LED Driver (CC)
LIM-15T

Independent design

Dimmable constant current driver

Analogue flicker-free

Dimming with leading edge or trailing edge dimmer

Smooth dimming compatible with most dimmer

Dimming range 1…100%

Configurable constant current output via dip-switch

Captured terminal screws

Protections: opencircuit, shortcircuit, overload, over temperature

SELV equivalent

Suitable for class I & II luminaires

Protection class II
