12V 150W 1-10V Dimming LED Driver (CV)
V6-150-12A

Independent desig

Dimmable constant voltage driver

Dimmable via 1...10V interface

Analogue flicker-free

Dimming range: 1...100%

Built-in active PFC function

Primary and secondary sides come with leads

Protections: opencircuit, shortcircuit, overload, overtemperature

Differential mode 4kV and common mode 6kV surge immunity

SELV equivalent

Protection class I

IP67 design
