8-10W Built-in TRIAC Dimming LED Driver (CC)
MINI Series

Super compact design for built-in use

Dimmable with trailing edge dimmer

Smooth dimming compatible with most dimmer

Dimming range from 1…100%

Primary and secondary sides come with leads

Protections: opencircuit, shortcircuit, overload

DC input compatible (176-250Vdc)

Seal with glue, the operating temperature up to 60°C

Suitable for protection class I & II luminaires

Parameters Qualifications Download

Model No. 型号	Mominal Voltage 额定电压	Power Factor 功率因素	Max. Output 功率	Output Current 输出电流	Output Voltage 输出电压	Efficiency Full Load 效率	Standby Power 待机功耗	Ambient Temperature 环境温度ta	Max. Case Temperature 最大外壳温度tc	Dimensions LxWxH 产品尺寸
MINI-8-150T	220-240V	0.90C	8W	150mA	27-44V	78%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-8-180T	220-240V	0.90C	8W	180mA	22-44V	80%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-8-200T	220-240V	0.90C	8W	200mA	20-40V	81%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-8-350T	220-240V	0.90C	8W	350mA	12-23V	80%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-8-500T	220-240V	0.90C	8W	500mA	8-16V	76%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-8-700T	220-240V	0.90C	8W	700mA	6-12V	75%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-10-230T	220-240V	0.90C	10W	230mA	22-44V	81%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-10-250T	220-240V	0.90C	10W	250mA	20-40V	82%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-10-260T	220-240V	0.90C	10W	260mA	20-39V	81%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-10-300T	220-240V	0.90C	10W	300mA	17-34V	82%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-10-350T	220-240V	0.90C	10W	350mA	14-29V	82%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-10-450T	220-240V	0.90C	10W	450mA	11-22V	79%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-10-500T	220-240V	0.90C	10W	500mA	10-20V	79%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-10-600T	220-240V	0.90C	10W	600mA	9-17V	79%	n/a	-20 ... 60℃	90℃	58x36x20mm
MINI-10-700T	220-240V	0.90C	10W	700mA	7-15V	77%	n/a	-20 ... 60℃	90℃	58x36x20mm
